4.5 Removing and installing rear left interior
locking switch - E273- / rear right interior
locking switch - E274-
Removing
– Switch off ignition and take out ignition key.
– Remove relevant door trim ⇒ Rep. gr. 70 .
– Unplug electrical connector -2-.
– Release retainers -arrows- and press central locking switch
out of door trim towards passenger's compartment.
Installing
Installation is carried out in the reverse order; note the following:
– Install door trim ⇒ Rep. gr. 70 .
4.6 Removing and installing door contact
switch
The door contact switch is located in the door lock and cannot be
renewed separately if defective.
– Renewing rear door lock ⇒ Rep. gr. 58 .
4.7 Removing and installing door warning
lamp and entry light
Removing
– Use flat screwdriver to press in retaining tab -1- and pry out
door warning lamp/entry light -2-.
– Unplug electrical connector -3-.
– If fitted, carefully pry off cover at door warning lamp -arrow-.
Audi A8 2003 ➤
Electrical system - Edition 08.2014
4. Lights and switches in rear doors 285
