– Unscrew bolts -arrows- and detach retainer -1- of control unit
for headlight range control -J431- from central tube for dash
panel.
– Unplug electrical connector -2-.
– Unscrew nuts -arrows- and detach control unit for headlight
range control - J431- -item 1-.
Installing
Installation is carried out in the reverse order; note the following:
– Install instrument cluster ⇒ page 83 .
Tightening torques
Component Nm
Control unit to bracket 2.5
Bracket to central tube for dash panel 3.0
Audi A8 2003 ➤
Electrical system - Edition 08.2014
25. Automatic headlight range control 263
