4.14 Removing and installing voltage con‐
verter for rear left/right door background
lighting
Removing
– Remove relevant door trim ⇒ Rep. gr. 70 .
– Unplug electrical connectors -1- and -2-.
– Unscrew bolts -arrows- and detach voltage converter for back‐
ground lighting (rear).
Installing
Installation is carried out in the reverse order; note the following:
– Install door trim ⇒ Rep. gr. 70 .
Tightening torque
Component Nm
Voltage converter for background lighting to
door trim
1.2
Audi A8 2003 ➤
Electrical system - Edition 08.2014
348 Rep. gr.97 - Wiring
