– Unscrew body brace -arrow-.
– Remove bolts -1- and -2-.
– Detach bracket -3- for body brace.
Vehicles with coolant expansion tank in plenum chamber:
– Remove rear section of front left wheel housing liner ⇒ Rep.
gr. 66 .
– Clamp off coolant hose -2- with hose clamp -3094- .
– Unplug electrical connector -1- at coolant shortage indicator.
– Place drip tray for workshop hoist - VAS 6208- beneath coolant
expansion tank and detach coolant hose.
– Unscrew securing bolt -2- at coolant expansion tank.
– Release retaining clips -arrows- and take coolant expansion
tank -1- out of mounting.
Audi A8 2003 ➤
Electrical system - Edition 08.2014
2. Windscreen wiper system 117
