9 - 6 Nm
10 - 3 Nm
11 - Bulb
Main beams
❑ H7 - 12 V, 55 W
❑ Renewing bulb ⇒ page 162
Daytime running lights
❑ 12 V, 21 W
❑ Renewing bulb ⇒ page 164
LED light
❑ If the LED module fails the headlight must be renewed as a complete unit
12 - Bulb for side lights
❑ Glass base bulb 12 V, 5 W
❑ Changing bulb - vehicles without static cornering light ⇒ page 166
❑ Changing bulb - vehicles with static cornering light ⇒ page 167
❑ There is no bulb in headlight with LED light; if faulty, the LED module must be renewed as a complete
part
13 - Bulb holder
❑ For bulb for side lights
14 - Bulb for static cornering light
❑ H8 - 12 V, 35 W
❑ Renewing bulb ⇒ page 165
15 - Main beam housing cover
❑ Release retaining tabs to remove
16 - Knurled nut
❑ To adjust headlight to bumper contour
17 - 6 Nm
18 - Gas discharge bulb
❑ 35 W, D2S
❑ Renewing bulb ⇒ page 158
19 - Starter unit for gas discharge bulb
❑ Removing and installing: vehicles up to 08.2007 ⇒ page 159 , vehicles from 09.2007 onwards
⇒ page 161
20 - 1 Nm
21 - Output module
❑ Depending on version and equipment
❑ Output module for left headlight - J667-
❑ Output module for right headlight - J668-
❑ Removing and installing ⇒ page 172
22 - Seal
❑ Renew if damaged
23 - Housing cover for gas discharge bulb
24 - 1 Nm
25 - Headlight range control motor
❑ Left headlight range control motor - V48-
❑ Right headlight range control motor - V49-
Audi A8 2003 ➤
Electrical system - Edition 08.2014
148 Rep. gr.94 - Lights, bulbs, switches - exterior
