Operation
9
CCD CAM 100 – Installation and Operating Manual 125/198
9.8.1 Menu Structure
Operating Display
Application Settings
Lens Settings
Lens Settings
Setting of aperture, focus and exposure time
Aperture, Focus, Exposure
Exposure Setup
LED-Marker and Focus
Defining the exposure settings
Setting of measuring range and focus
Edge Definition
Definition Edge [1..8]
Definition Area [1..8]
Sensitivity Edge [1..8]
Scan Direction
Edge Definition
Material Parameter
White Balance
Defining edges
Defining the edge detection area
Defining the edge detection sensibility
Defining the scan direction
Material Parameter
White Balance
Dist. Lower Edge mm
Mat. Thickness mm
Defining the distance of the bottom side of the
material to the sensor level of the CCD camera
Defining the material thickness
Fig.72: Structure of the Application Settings menu
