Design and Function
20/198 CCD CAM 100 – Installation and Operating Manual
3 Design and Function
3.1 Utilization
The CCD camera CCD CAM100 permits the contact-free position
measurement of contrast transitions (e.g. material edges) on the
running material webs. Their standard application area is for
■ Web edge guiding
■ Web center-line guiding
■ Web width measurement
Depending on the web width, the desired measuring accuracy
(resolution) and the application case, one or two CCD cameras are
used.
Single camera system
CAN Address = 21
Left
edge
Fig.1: Guiding to the left web edge
CAN Address = 21
Right
edge
Fig.2: Guiding to the right web edge
