BST CCD CAM 100 User Manual

Commissioning
8
CCD CAM 100 – Installation and Operating Manual 87/198
8.9 CCD Camera Alignment
8.9.1 Aligning Steps
Y axis
X axis
Z axis
LED projection point
Measuring range
Fig.53: CCD camera alignment
The process for aligning the CCD camera is divided into five steps.
Step Setting See Chapter
Aligning the X axis X Axis Alignment, page 93
Aligning the Y axis Y Axis Alignment, page 94
Setting the
measuring range
Measuring Range Setting,
page 95
Setting the focus
(set LED projection
points focused)
Focus Setting, page 96
Aligning the Z axis Z Axis Alignment, page 98
