CCD CAM 100 – Installation and Operating Manual 133/198
9.8.4 Setting the Measuring Range and Focus
\ Lens Settings \ LED-Marker and Focus
The LED-Marker and Focus menu is used to check and, if required,
correct the settings for the measuring range and the focus of the
CCD camera.
Fig.76: LED-Marker and Focus menu
The measuring range and the focus are set when aligning the CCD
camera during the commissioning process (alignment steps 3 and
4). The LED-Marker and Focus menu allows to check and correct
both settings without having to go through the complete setup
process for the camera alignment (XYZ-Axis Adjustment).
After calling up the menu, the LED projection points are automat-
ically switched on.
The procedure for setting the measuring range and the focus is
described in detail in the following chapters:
Measuring Range Setting, page 95
Focus Setting, page 96
Setting the Focus, page 128
