Design and Function
32/198 CCD CAM 100 – Installation and Operating Manual
3.7.5 DIL Switch
The DIL switch S1 is located behind the cover of the service opening.
Fig.15: DIL switch S1
NOTICE
Damage to components when working on live parts.
►
Before opening the housing, switch off the power supply.
The function of the DIL switches is described in chapter Setting the
DIL Switches, page 72.
3.8 Accessories
For accessories and the order address, see Accessories and Spare
Parts, page 185.
