Electrical Connection
7
CCD CAM 100 – Installation and Operating Manual 67/198
7.5 Connecting the Light Box
7.5.1 Light Box Types
Four standard light box types (XS, SL, XL, MLLA) with LED lighting
are available for different lighting requirements.
Light Box Type Operating Mode Brightness Control Wiring Diagram
XS, SL, XL
Operation on external
24V⎓ power supply
No brightness control
(100% permanent light)
See Operation on External Power
Supply, page 68.
MLLA
Operation on external
24V⎓ power supply
No brightness control
(100% permanent light)
See Operation on External Power
Supply, page 68.
Operation on
CCDCAM100
Brightness of two light boxes
(LED1, LED2) adjustable via
the camera interface of the
CCDCAM100 (0…100%)
See Operation on CCD CAM 100,
page 69.
The technical data for the different light box types can be found in
chapter Light Boxes, page 186.
7.5.1.1 Light Box Types XS, SL and XL
The light boxes of the XS, SL and XL types are used for the detec-
tion of the web edge positions using the transmitted light method.
They are connected to an external power supply (24 V⎓) and
provide permanent light with a brightness of 100%. Brightness
control is not possible with these light box types.
7.5.1.2 Light Box Type MLLA
The light box of the MLLA type was specially developed for the
reflected light method. It can be optionally connected to an
external power supply (24 V⎓) or directly to the CCD CAM 100
CCD camera. When operated on the external power supply, it
provides permanent light with a brightness of 100%. When
operated on the CCDCAM100, the brightness of two light boxes
can be adjusted via the camera interface of the CCD camera
between 0% and 100%.
