3.9 Name Plate
The name plate is located on the camera housing in the area of
the connections.
The nameplate displayed is only an example. Please obtain the
current data from the nameplate attached to the product.
Fig.16: Example of a name plate
Pos. Field Meaning
① Address Manufacturer address
② Certificates CE designation
③ IDC Serial number
④ Type Type designation
⑤ U Operating voltage
⑥ PC
Date of manufacture
(Year / Calendar week)
⑦ Rev
Hardware version (e.g. BI),
Firmware version (e.g. 1.5.2)
⑧ I Nominal current consumption
⑨ Code
Data matrix code,
Content = 30 digit serial number (IDC)
⑩ IP Protection type
