Commissioning
8
CCD CAM 100 – Installation and Operating Manual 77/198
8.4.3 Setup Wizard
In the Normal Setup menu a setup wizard guides you through the
commissioning process step by step.
When commissioning the CCD camera, we recommend to
complete all menu items of the Normal Setup one after
another.
Procedure
Requirement: The Normal Setup menu is selected (procedure see
Quick Setup and Normal Setup, page 75).
1. Select the desired menu item with the arrow buttons.
The menu item selected is highlighted in blue.
Note: As an alternative, you can also tap the desired menu item
directly on the touchscreen. The menu is then opened immedi-
ately.
2. Confirm the selection with the button.
The first page of the selected menu appears on the screen.
3. Carry out the desired settings in the menu.
4. Press the button.
The second page of the selected menu appears on the screen
(with multipage menus).
5. Carry out the desired settings in the menu.
6. Press the button.
