Design and Function
22/198 CCD CAM 100 – Installation and Operating Manual
3.2 Design
Web guiding
A standard web guiding system comprises the following components:
■ One or two CCD cameras*
■ One or two light boxes*
■ One BST web guiding controller (e.g. ekr500digital)
■ One guiding device (e.g. rotating frame guide)
■ One set of connecting cables
* Number depends on guiding type and web width
Web width measurement
A standard system for web width measurement comprises the
following components:
■ One or two CCD cameras*
■ One or two light boxes*
■ One BST web guiding controller (e.g. ekr500digital)
■ One external control keyboard efedigital
■ One set of connecting cables
* Number depends on guiding type and web width
