Chery QQ Service Manual Transmission System
3.Blow oil pipeline.
1- Input shaft
2-
Oil pipeline
Fig.3-25
4. Assemble the synchronizer assembly, insert 3 synchronizer insert, and then
install the spring according to the Fig.
1- Snap ring
2-
Synchronizer insert
3-Hub
4- Hub sleeve outer race
5-3rd gear
-65-
Fig.3-26
Notice:
Keep right directions of every part.
Pay more attention to the size differences of spring snap ring, synchronizer
insert, hub sleeve and synchronizer assembly.
5. Use special tool to install right bearing of input shaft.
