Chery QQ Service Manual
Syringe dose not work, rear wiper
dose not work
1． Wiper switch
2． Rear wiper motor
3． Harness
No cleaning solution sprayed
1． Syringe tube and nozzle
2． Syringe motor
3． Wiper switch
4． Syringe fuse
5． Harness
Wiper contact car body when wiper
in high speed gear
1． Wiper blade
2． Wiper connecting rod location
Wiper blade dose not return to
original position or return not
completely when close the wiper
1． Power supply fuse
2． Wiper motor
3． Adjust improper
4． Harness
Tachometer, fuel meter and coolant
temperature meter don’t work
1． Instrument fuse
2． Instrument circuitry template
3． Bulb
4． Harness
5． Sensor
Speedometer dose not work
1． Vehicle speed sensor
2． Instrument circuitry template
3． Speedometer
4． Harness
Tachometer dose not work
1． Engine ECU
2． Engine tachometer
3． Instrument circuitry template
4． Harness
Fuel meter work abnormally or
dose not work
1． Fuel meter
2． Fuel sensor
3． Instrument circuitry template
4． Harness
Coolant temperature meter dose not
work
1． Coolant temperature meter
2． Coolant temperature sensor
3． Instrument circuitry template
4． Harness
Illuminating lamp dose not light
1． Small lamp fuse
2． Instrument circuitry template
3． Illuminating lamp dimmer
4． Bulb
5． Harness
Instrument and
illumination
combination
meter
One illuminating lamp dose not
light
1． Bulb
2． Harness
3． Corresponding function part
- 35 -
