Engine fault warning lamp dose not
light
1． Engine ECU
2． Instrument circuitry template
3． Harness
Fuel fluid level warning lamp dose
not light
1． Fuel fluid level warning switch
2． Instrument circuitry template
3． Bulb
4． Harness
Oil pressure warning lamp dose not
light
1． Bulb
2． Oil pressure switch
3． Instrument circuitry template
4． Harness
ABS warning lamp dose not light
1． Bulb
2． ABS computer
3． Instrument circuitry template
4． Harness
Seat belt warning lamp dose not
light
1． Bulb
2． Instrument circuitry template
3． Buckle switch
4． Harness
Warning lamp
and indicator
lamp
Braking warning lamp dose not
light
1． Bulb
2． Parking brake switch
3． Brake fluid level warning lamp
4． Instrument circuitry template
5． Harness
Air bag warning lamp dose not
light
1． Bulb
2． Air bag sensor assembly
3． Instrument circuitry template
4． Harness
Door open warning lamp dose not
light
1． Vehicle interior fuse
2． Bulb
3． Gating switch
4． Instrument circuitry template
5． Harness
Upper beam indicator lamp dose
not light
1． Bulb
2． Instrument circuitry template
3． Headlamp switch
4． Harness
Turning indicator lamp dose not
light
1． Bulb
2． Instrument circuitry template
3． Turning switch and hazard
warning switch
4． Harness
