System 3505 Installation & Operation Manual
Digitize, Inc. 700248-0002 Rev. C 02/16
Specification Subject to Change Without Notice
1-1
1 GENERAL INFORMATION
This manual provides the basic installation and operating procedures and instructions for the
DIGITIZE SYSTEM 3505. Illustrations are provided throughout to familiarize the operator with
the terminology used in this manual. Operators and installers are advised to study the illustrations
and System descriptions before reading the operating procedures. All installation and testing
should be performed by factory trained personnel.
This manual was developed and intended for use with System 3505 9
th
Edition Program Revision
S790STD1.BIN.
1.1 LISTING AND APPROVAL INFORMATION
System 3505 Listings and Approvals:
▪ ETL listed under ANSI/UL 864 [Control Units and Accessories for Fire Alarm Systems]
▪ ANSI/UL 1076 [Proprietary Burglar Alarm Units and Systems]
▪ ANSI/UL 1610 [Central Station Burglar Alarms]
▪ NFPA72 Compliant
▪ CFM Listed (California Fire Marshall).
NOTE: Not all features, hardware, and selections may comply with ANSI/UL 864 listing
requirements but are beneficial for some customers. These items are noted as exceptions to
the requirements for listing conformity
.
1.2 ANSI/UL 864 STANDARD & SYSTEM SETTINGS
All System 3505 units are shipped with options preset to conform to ANSI/UL 864. The user
may elect to make changes to some settings that may not conform to that standard. These
changes are as follows:
1. The SYSTEM 3505 is shipped with O/S capability limited at a slave unit to only impact
the Slave System 3505. The user can elect to activate a capability to allow a Slave
System 3505 to take an account O/S at the master as well as at all the Slave units in a
Networked System.
2. The Network Option 7 SET menu allows the user to cause an ACK to be routed to the
other System 3505 units for remote ACKnowledge. The default settings are for the
Manual ACK not to be routed to the network or impact the Remote Annuciator ACK
selection. An ACK from the Remote Annunciator unit, or simply transferring an account
from the System 3505 to the Remote Annunciator to not ACK anything. The user can
overrided thise settings and select to ACK the local 3505 on good transfer of an account
to the Remote Annunciator or ACK the System 3505 if the operator ACKs the RA, or to
send any of these ACK signals on the network to allow selection of processing the ACK
at another System 3505. This includes selections within the SET menus 29 and 34.
3. In the 11 SET menu for 1221 Radio, the user is able to change the default carrier alarm
notification from the preset of 15 seconds (the setting that conforms to ANSI UL 864
standards) to 30, 45, 60, 75 or 90 seconds to foreign carrier notification. Changes to the
factory preset may not conform to the UL standard
4. In the 12 SET menu for 1221 Radio, the user can change the failure notification that no
radio box has been received from the factory default of 1 hour (a setting that conforms to
