22-2
Multiple alarms may be assigned to the same PPO-64T output point. When the last zone
assigned to the PPO-64T is secured, only then will the PPO point turn OFF. (Software
version 6.04 Std 1 rel. 10/27/97 required for this feature.) Up to 250 separate points or
relays may be turned on at the same time
The user text message screen is illustrated below:
WATER FLOW
3RD FLOOR
BLDG 53 @T123, 22, 54
ALM ZN 23-5
For more details concerning user text messages, refer to Section 4, User Text.
Requires PPO-64T with PPO Command (Opt 7=40).
22.4 RELAY COMMANDS (@R)
A relay command format may be any of the following forms:
@R123-14 translates to: DGM Panel #123, Relay #14 (ON for Alarm, OFF for Secure or
Trouble).
@R123-14M translates to: DGM Panel #123 Relay #14 Momentary ON Alarm (No
action for Trouble or Secure)
@R123-14T translates to: DGM Panel #123 Relay #14 (ON for Trouble, OFF for
Secure or Alarm).
@R123-14TM translates to: DGM Panel #123 Relay #14 (Momentary ON for Trouble,
No action for Alarm or Secure).
@R9001-14 translates to: Q-Mux Node # 9001 Relay #14 (ON for Alarm, OFF for
Secure or Trouble).
To cascade activations, enter @R12-5,123-14M, 1-1.
This translates to:
DGM Panel #12 Relay #5 (ON Alarm, OFF Trouble and Secure).
DGM Panel #123 Relay #14 Momentary ON Alarm (No action Trouble or Secure)
DGM Panel #1 Relay #1 (ON Alarm, OFF Trouble or Secure).
22.5 PAGER COMMANDS (@P)
The user has the option to enter exceptions to the default page groups. Exceptions are
programmed by entering an ‘@P’ code on the zone specific user text message screen (via
the external keyboard). Entries on the user text message screen override any default
groups assigned.
The Pager code format is as follows:
@Px, x, x where x represents the Group # to which to send the page. Up to 16
groups may be listed.
A Pager code of ‘@P1, 5’ translates into ‘page Groups 1 and 5’.
