DIGITIZE SYSTEM 3505 - Installation; Handling; Unpacking and Inspection; Installation Procedure

System 3505 Installation & Operation Manual
Digitize, Inc. 700248-0002 Rev. C 02/16
Specification Subject to Change Without Notice
2-1
2 INSTALLATION
2.1 HANDLING
CAUTION! Do not touch internal circuitry during installation because static discharge
may damage components. If access to the interior of the unit is required, follow the
standard precautions set for handling CMOS circuitry.
2.1.1 Unpacking and Inspection
Before opening, inspect the shipping container for unusual damage. Then unpack the
contents and inspect for scratches, dents, or loose internal components. If inspection
reveals any physical damage, retain the packing material and contact the carrier
immediately. Each unit has been thoroughly inspected prior to shipment.
2.2 INSTALLATION PROCEDURE
The SYSTEM 3505 is designed for 19 in. rack mounting and occupies seven inches of
vertical rack space. Each unit has four mounting holes located on the front panel and is
supplied with four special mounting washers in a small envelope attached to the front panel.
Mounting screws, regardless of size or thread type, must have a cone head shape (not flat
head). Mounting the SYSTEM 3505 by way of the front panel will support itself and all
attachable options. No other supports are required.
2.2.1 Field Wiring
All field wiring must be tested for grounds, induced or abnormal voltages, open and
shorted circuit conditions. All field wiring must be free of these conditions prior to
connecting them to the SYSTEM 3505. Do not connect field wiring until the
SYSTEM 3505 has been fully tested beforehand. Tag all wiring for later connection
to the unit. NOTE: Failure to comply with these guidelines may cause damage to the
unit. Refer to the Appendix D, SYSTEM 3505 Installation Drawing #800321 for
electrical connection.
Note: The System 3505 is shipped with a cardboard guide plate outside of the
thermal printer paper supply reel for protection. This cardboard guard must be
removed from the supply real prior to System start-up.
2.2.2 Font Selections
Through the 4 Set Menu on the System 3505, the user can select the print font and
print quantity for each Alarm priority level, Trouble & Restore. The user can also
select what to print for look up as well as FUNC 07. The two sample thermal
printouts illustrate how the style can be modified for an Alarm, for example, and then
the font for Trouble and Restore changed on the printout.
