DIGITIZE SYSTEM 3505 - Transmit SST Fast; Transmit SST Slow; Stop SST Transmit; All out 22, 22+BX

System 3505 Installation & Operation Manual
Digitize, Inc. 700248-0002 Rev. C 02/16
Specification Subject to Change Without Notice
6-6
6.2.5 Transmit SST Fast
Once satisfied the box number and the number of rounds have been loaded
correctly, press the TRANSMIT SST FAST button to start box transmission via
the SST fast relay.
6.2.6 Transmit SST Slow
Once satisfied the box number and the number of rounds have been loaded
correctly, press the TRANSMIT SST SLOW button to start box transmission via
the SST fast relay.
6.2.7 Stop SST Transmit
To abort the Transmission, press “STOP SST TRANSMIT”. Reverse video
prompts the operator to press the STOP SST TRANSMIT to abort the Solid State
Transmitter. It is also used to momentarily turn ON (TOGGLE) a DGM relay for
two seconds when under relay control option.
6.2.8 All Out 22, 22+BX
Initiates All Out plus box number.
6.2.9 Relay Lookup
Appears on systems with the Relay Control Option installed.
6.2.10 Status Printout
To initiate printout of all zones, boxes and system errors which are not SECURE,
or those which are OUT OF SERVICE.
6.2.11 Print Set Report
Some screens will display this key whenever the PRINT button is shown on the
screen.
6.2.12 Abort Print Set
Aborts current SET printout.
6.2.13 FACP Faults
Units connected to FCI-7200 fire panel version 5.x or higher will display this key
whenever a panel fault is reported.
6.2.13.1 Printer Rewind Motor
Press the (unknown) button to bring up the PRINTER REWIND OFF/ON
selection.
6.2.13.2 Scroll Keys
Upon activation of an Alarm, Trouble, or Restore condition, the SYSTEM
3505 will automatically display all generic and zone specific messages (if any).
If the item currently displayed in bold text has multi-page pages, a
SNGL/MULT PAGE DISP key will appear.
