System 3505 Installation & Operation Manual
Digitize, Inc. 700248-0002 Rev. C 02/16
Specification Subject to Change Without Notice
1-7
1.8.7
Temperature and Humidity
The SYSTEM 3505 operates best in an environment that is controlled for the comfort
of operating personnel, with respect to levels of temperature, humidity, and dust
content. The SYSTEM 3505 will operate satisfactorily however, within the range of
environmental conditions as listed:
Operating Temperature ........................... 32 to 120ºF (0 to 49ºC)
Storage Temperature ............................... 14 to 158ºF (-10 to 70ºC)
Operating Humidity ................................ 0 to 85% (non-condensing)
Storage Humidity .................................... 0 to 85% (non-condensing)
1.8.8
Strip Printer
Method .................................................... Thermal transfer
Print Head: ............................................ Fixed head, 576 Dot array
Characters:
Full Graphic printer
Print width ........................................ 72mm
Resolution ........................................ 8 dots/mm
Print speed ........................................ 75mm/s
Paper:
Roll Size .......................................... 3.125"W x 220'L x 2.825"Diameter
Color ................................................. White
Print Image ...................................... Black
Capacity .......................................... 1500+ Alarms/roll
1.8.9
Display
Format 320 x 240 pixels, electroluminescent
Character Set .......................................... 96 character ASCII
Font ......................................................... English, General European
Font Size
Date/Time and Main Alarms ..... 0.192 in.
All Other Text ............................ 0.094 in.
Color ....................................................... Neon Yellow
Mean Time Between Failure (MTBF) .... 100,000+ Hours
Viewing Angle ........................................ 160 Degrees
Brightness ............................................... 30 ft -Lumens (min)
Viewing Area .......................................... 4.5 in wide x 3.4 in. high
1.8.10
Keypad
The front panel keyboard is of “Mono-panel” design. The keyboard consists of 32
membrane key switches, two of which have an embedded LED indicator: the ACK
and CLEAR keys. The push buttons have a life expectancy rating in excess of 10
million actuations and will operate reliably throughout the entire operating ranges
specified on the preceding pages. Five of the 32 keys are soft keys and are present
based on the options installed and features activated.
1.9 FCC REQUIREMENTS
The SYSTEM 3505 complies with the limits set for a Class A computing device as specified
in Subpart J of Part 15 of the Federal Communications Commission “Rules and Regulations”.
