1.8 SPECIFICATIONS
1.8.1 Fuses
AC line input fuse ......................................... 3.0 Amp. (fast-blow)
1.8.2 Inputs
Supervised AC Power .................................... Detachable Cord
Supervised Standby Battery .......................... 24 Volts D.C.
Remote Inputs .. …………………………….Option Remote Inputs 1-4 are used for
the single circuit “Telegraph Coded
Input” option.
EXT Inputs 1-6 EXT 4, 5, and 6 are supervised.
Supervisor Charger Fail Input
SEBB RS-485 Communication
Time Reference RS-485 Clock Input
1.8.3 Outputs
AUDIO OUT: “Line” level output, (1 Volt P-P) identical to that of the front
panel speaker for connection to an external amplifier or P.A.
System (not supervised).
SST FAST: Normally open and normally closed “dry” relay contacts used for
special options (not supervised).
SST SLOW: Normally open and normally closed “dry” relay contacts used for
special options (not supervised).
ALARM: Energized based on SET MENU selection.
TROUBLE: Normally energized when System operates properly.
AUX 1: Energized based on special options
POWERS 1 & 2: Provides a power supply for external line driver racks and the
DDI-10E (Not an ETL Listed Component).
CAUTION: NEVER USE THESE CONNECTIONS TO POWER ANY
OTHER DEVICES.
1.8.4 Construction
The enclosure and cover of the SYSTEM 3505 is made of 0.062" aluminum. A
membrane keypad is mounted on a 0.093" aluminum front panel.
1.8.5 Dimensions
Height .................................................... 6.97" (17.7 cm)
Width ...................................................... 19.0" (48.3 cm)
Depth ...................................................... 15.5" (39.5 cm)
1.8.6 Weight
Net Weight ............................................. 21.3 lb. (9.7 Kg)
Shipping Weight ..................................... 25.0 lb. (11.38 Kg)
