REORDER PAPER P/N: 900134-0005
REFER TO SECTION 2 OF THE 3505 OPERATING MANUAL
1. RAISE & LOWER PRINTER LEVER TO REMOVE REMAINING
PAPER FROM THE PRINTER & ACTIVATE AUTO-FEED.
2. REPLACE EMPTY SPOOL WITH NEW PAPER ROLL.
3. REMOVE METAL DISK & USED ROLL FROM THE TAKE-UP REEL.
4. FEED NEW PAPER INTO PRINTER (AUTO-FEEDS) FOLLOWING
THE GUIDE ABOVE. PRESS 'PAPER ADVANCE' BUTTON FOR
MORE FEED.
5. THREAD THE PAPER OVER THE GUIDE PIN & THROUGH THE
WINDOW.
6. PLACE EMPTY SPOOL ON THE TAKE-UP REEL. TAPE NEW PAPER
TO EMPTY SPOOL.
7. REPLACE METAL DISK, MAKING IT SNUG TO THE EMPTY SPOOL.
8. PRESS THE 'KEY SELECT' BUTTON, THEN THE 'PRINTER REWIND
ON' BUTTON, THE PRINTER IS NOW READY
Place paper over
guide pin.
Printer lever
PLASTIC
SPOOL
2-3 Thermal Printer Replacement
