example for table #1 when the subscriber unit reports a zone 01, the translation
table will set up to report account 1234-01 in Alarm. Please note that zone 01 is
an arbitrary zone and may or may not match the exact zone activated on the
Digital Dialer. If reporting the exact zone activated on the dialer is important,
this information can be indicated in the account specific message that is
programmed for this account/zone combination. When this dialer reports 1234-
21, this is the restoral code for indicating that the previously reported zone 01 has
now restored. The SYSTEM 3505 will restore account 1234-01. Note that the
reported zone from the dialer is never displayed by the 3505, but rather is used to
look up the conversion table and determine what it should do. In this case it is to
restore zone 01. To report a Trouble condition for this same zone, the dialer
reports 1234-61, this translates to Trouble zone 11, processed as 1234-11 by the
system 3505. Note again that assignment to zone 11 is arbitrary. The dialer
reports 1234-71, which needs to be translated to a restoral condition for this
Trouble, reported as 1234-11 restore by the SYSTEM 3505. The following table
illustrates what signal is reported by the subscriber unit, and how the SYSTEM
3505 processes it based on table #1 or #2.
Subscriber reports SYSTEM 3505 reports
Using Config #1
1234-01 1234-01 Alarm
1234-21 1234-01 Alarm Restore
1234-61 1234-01 Trouble
1234-71 1234-01 Trouble Restore
Using Config #2
1234-02 1234-01 Alarm
1234-F1 1234-01 Trouble
1234-E1 1234-01 Restore
Some zone numbers sent in by the subscriber use English equivalents to describe
the account. Note the translation based on config #1 & #2.
Subscriber reports SYSTEM 3505 reports
Using Config #1
1234-30 Daily test
1234-69 Battery fail
Using Config #2
1234-E9 Daily test
WARNING! Never duplicate codes within a Configuration. The SYSTEM 3505
will only recognize the first occurrence of the code. Printing the Configuration Table and
thoroughly checking for any code repetitions is strongly recommended. The SYSTEM
3505 will check all eight config tables for any that contain duplicate zone codes when
exiting the 16 SET menu, or on power up of the SYSTEM 3505 unit.
The SYSTEM 3505 will check on all eight config tables for any that contain duplicate
zone codes upon exit of the 16 ET menu or upon power-up of the SYSTEM 3505 uit.
Do not enter the same subscriber account regardless of the config table used. The
SYSTEM 3505 will not accept duplicate subscribers.
