E 12
- Remove the retaining bolt (6) from the swivel arm.
- Secure the standing legs (22) in the top position with the bolt (23).
- Mount the ultrasonic sensor and holder (1) to the slewing belt.
- Check the tension of the conveyor belt, proceed with maintenance if necessary.
- Trial operation:
- Proceed with trial operation of the slewing belt, test slewing and height adjustment.
- Check functions of the chain lubrication system and spraying system.
