E 15
- Using the pump, slowly retract the lift
supports until they no longer have any
contact with the ground.
A
If necessary, adjust the changeover
valve at the pump.
- The bearing (4) is now in
the opening (5).
m
To proceed, the relative positions of the
through holes and positioning
holes (9,10) for the bolt (3) must be as
shown! Check this on both sides of
the vehicle!
