E 16
- Connect the hydraulic hoses (11) and
the supply line of the spraying
system (12) and chain lubrication sys-
tem (13) of the slewing belt with the
corresponding quick-release cou-
plings of the feeder.
- Remove the dummy connector (14)
and insert the slewing belt connector;
secure it with the corresponding
shackles.
m
All hydraulic hoses (11) must be coupled
properly to prevent a greater increase in
pressure. Check that connected cou-
plings fit properly!
