Chapter 29

| IP Routing Commands

Policy-based Routing for BGP

– 1012 –

Example

Console#show route-map RD

route-map RD, permit, sequence 1

Match clauses:

peer 102.168.0.99

Set clauses:

comm-list 100 delete

Call clause:

Action:

Exit routemap

Console#
