Chapter 21
| Data Center Bridging Commands
Enhanced Transmission Selection Commands
– 558 –
show ets mapping Use this command to display mapping from IEEE 802.1p priorities to the traffic class
group (TCGs).
Syntax
show ets mapping [interface interface]
interface
ethernet unit/port
unit - Unit identifier. (Range: 1)
port - Port number. (Range: 1-32/54)
port-channel channel-id (Range: 1-16/27)
Command Mode
Privileged Exec
Example
This example shows both the locally configured settings, and current operational
settings.
Console#show ets mapping interface ethernet 1/5
Configuration:
ETS Mode: Auto
Priority Traffic Class
-------- -------------
0 0
1 0
2 0
3 0
4 0
5 0
6 0
7 0
Operational:
ETS Mode: On
Priority Traffic Class
-------- -------------
0 0
1 0
2 0
3 0
4 0
5 0
6 0
7 0
Console#
