Chapter 29
| IP Routing Commands
Global Routing Configuration
– 818 –
â—† If both static and dynamic paths have the same lowest cost, the first route
stored in the routing table, either statically configured or dynamically learned
via a routing protocol, will be used.
â—† Static routes are included in RIP, OSPF and BGP updates periodically sent by the
router if this feature is enabled by the RIP, OSPF or BGP redistribute command
(see page 826, 847, 889 or 940 respectively).
Example
This example forwards all traffic for subnet 2001::/64 to the next hop router
2001:DB8:2222:7272::254, using the default metric of 1.
Console(config)#ipv6 route 2001::/64 2001:DB8:2222:7272::254
Console(config)#
Related Commands
show ip route summary (807)
show ipv6 route This command displays information in the Forwarding Information Base (FIB).
Syntax
show ipv6 route [ipv6-address[/prefix-length] | bgp | database |
interface vlan vlan-id] | local | ospf | rip | static]
ipv6-address - A full IPv6 address including the network prefix and host
address bits.
prefix-length - A decimal value indicating how many contiguous bits (from
the left) of the address comprise the prefix (i.e., the network portion of the
address).
bgp – Displays external routes imported from the Border Gateway Protocol
(BGP) into this routing domain.
database – All known routes, including inactive routes.
interface – Displays all routes that be accessed through this interface.
local – Displays all entries for destinations attached directly to this router.
ospf – Displays external routes imported from the Open Shortest Path First
(OSPF) protocol into this routing domain.
rip – Displays all entries learned through the Routing Information Protocol
(RIP).
static – Displays all static entries.
vlan-id - VLAN ID. (Range: 1-4094)
Command Mode
Privileged Exec
