Chapter 8
| General Security Measures
Port-based Traffic Segmentation
– 330 –
Example
Console#show ip arp inspection vlan 1
VLAN ID DAI Status ACL Name ACL Status
-------- --------------- -------------------- --------------------
1 disabled sales static
Console#
Port-based Traffic Segmentation
If tighter security is required for passing traffic from different clients through
downlink ports on the local network and over uplink ports to the service provider,
port-based traffic segmentation can be used to isolate traffic for individual clients.
Traffic belonging to each client is isolated to the allocated downlink ports. But the
switch can be configured to either isolate traffic passing across a client’s allocated
uplink ports from the uplink ports assigned to other clients, or to forward traffic
through the uplink ports used by other clients, allowing different clients to share
access to their uplink ports where security is less likely to be compromised.
traffic-segmentation This command enables traffic segmentation. Use the no form to disable traffic
segmentation.
Syntax
[no] traffic-segmentation
Default Setting
Disabled
Command Mode
Global Configuration
Table 61: Commands for Configuring Traffic Segmentation
Command Function Mode
traffic-segmentation Enables traffic segmentation GC
traffic-segmentation session Creates a client session GC
traffic-segmentation uplink/
downlink
Configures uplink/downlink ports for client sessions GC
traffic-segmentation uplink-to-
uplink
Specifies whether or not traffic can be forwarded
between uplink ports assigned to different client
sessions
GC
show traffic-segmentation Displays the configured traffic segments PE
