Chapter 19
| Class of Service Commands
Priority Commands (Layer 3 and 4)
– 523 –
show qos map dscp-
mutation
This command shows the ingress DSCP to internal DSCP map.
Syntax
show qos map dscp-mutation interface interface
interface
ethernet unit/port
unit - Unit identifier. (Range: 1)
port - Port number. (Range: 1-32/54)
port-channel channel-id (Range: 1-16/27)
Command Mode
Privileged Exec
Command Usage
This map is only used when the QoS mapping mode is set to “DSCP” by the qos
map trust-mode command, and the ingress packet type is IPv4.
Example
The ingress DSCP is composed of “d1” (most significant digit in the left column) and
“d2” (least significant digit in the top row (in other words, ingress DSCP = d1 * 10 +
d2); and the corresponding Internal DSCP and drop precedence is shown at the
intersecting cell in the table.
Console#show qos map dscp-mutation interface ethernet 1/5
DSCP mutation map.(x,y),x: PHB,y: drop precedence:
d1: d2 0 1 2 3 4 5 6 7 8 9
-----------------------------------------------------------------
0 : (0,0) (0,1) (0,0) (0,3) (0,0) (0,1) (0,0) (0,3) (1,0) (1,1)
1 : (1,0) (1,3) (1,0) (1,1) (1,0) (1,3) (2,0) (2,1) (2,0) (2,3)
2 : (2,0) (2,1) (2,0) (2,3) (3,0) (3,1) (3,0) (3,3) (3,0) (3,1)
3 : (3,0) (3,3) (4,0) (4,1) (4,0) (4,3) (4,0) (4,1) (4,0) (4,3)
4 : (5,0) (5,1) (5,0) (5,3) (5,0) (5,1) (6,0) (5,3) (6,0) (6,1)
5 : (6,0) (6,3) (6,0) (6,1) (6,0) (6,3) (7,0) (7,1) (7,0) (7,3)
6 : (7,0) (7,1) (7,0) (7,3)
Console#
show qos map
ip-port-dscp
This command shows the ingress TCP/UDP port to internal DSCP map.
Syntax
show qos map ip-port-dscp interface interface
interface
ethernet unit/port
unit - Stack unit. (Range: 1)
port - Port number. (Range: 1-32/54)
port-channel channel-id (Range: 1-16/27)
