Chapter 18

| VLAN Commands

Configuring VXLAN Tunneling

– 505 –

Example

Console#show vxlan vlan-vni

VLAN VNI

---- --------

1 10

2 200

3 123

Console#show vxlan vlan-vni 3

VLAN VNI

---- --------

3 123

Console#

show debug vxlan This command shows the VXLAN debug settings.

Syntax

show debug vxlan

Command Mode

Privileged Exec

Example

Console#show debug vxlan

VXLAN:

VXLAN event debugging is disabled

VXLAN database debugging is disabled

VXLAN VNI debugging is disabled

VXLAN VTEP debugging is disabled

Console#
