Chapter 4
| System Management Commands
System Status
– 121 –
â—† There are two thermal detectors in the switch The first detector is near the air
flow intake vents. The second detector is near the switch ASIC and CPU.
Example
Console#show system
System Description : AOS5700-54X
System OID String : 1.3.6.1.4.1.259.12.1.2
System Information
System Up Time : 0 days, 5 hours, 44 minutes, and 42.28 seconds
System Name :
System Location :
System Contact :
MAC Address (Unit 1) : 00-00-0C-00-00-FD
Web Server : Enabled
Web Server Port : 80
Web Secure Server : Enabled
Web Secure Server Port : 443
Telnet Server : Enabled
Telnet Server Port : 23
Jumbo Frame : Disabled
System Fan:
Force Fan Speed Full : Disabled
Unit 1
Fan 1: Ok
System Temperature:
Unit 1
Temperature 1: 39 degrees Temperature 2: 37 degrees
Temperature 3: 38 degrees Temperature 4: 31 degrees
Temperature 5: 31 degrees Temperature 6: 29 degrees
Temperature 7: 29 degrees Temperature 8: 36 degrees
Temperature 9: 36 degrees
Main Power Status : Up
Redundant Power Status : Not present
Console#
Table 14: show system – display description
Parameter Description
System Description Brief description of device type.
System Object ID MIB II object ID for switch’s network management subsystem.
System Up Time Length of time the management agent has been up.
System Name Name assigned to the switch system.
System Location Specifies the system location.
System Contact Administrator responsible for the system.
MAC Address MAC address assigned to this switch.
Web Server/Port Shows administrative status of web server and UDP port number.
Web Secure Server/Port Shows administrative status of secure web server and UDP port
number.
Telnet Server/Port Shows administrative status of Telnet server and TCP port number.
