Chapter 8
| General Security Measures
Port Security
– 260 –
The following example shows the port security settings and number of secure
addresses for a specific port. The Last Intrusion MAC and Last Time Detected
Intrusion MAC fields show information about the last detected intrusion MAC
address. These fields are not applicable if no intrusion has been detected or port
security is disabled. The MAC Filter ID field is configured by the network-access
port-mac-filter command. If this field displays Disabled, then any unknown source
MAC address can be learned as a secure MAC address. If it displays a filter identifier,
then only source MAC address entries in MAC Filter table can be learned as secure
MAC addresses.
Console#show port security interface ethernet 1/2
Global Port Security Parameters
Secure MAC Aging Mode : Disabled
Port Security Details
Port : 1/2
Port Security : Enabled
Port Status : Secure/Up
Intrusion Action : None
Max-MAC-Count : 0
Current MAC Count : 0
MAC Filter ID
: Disabled
Last Intrusion MAC : NA
Last Time Detected Intrusion MAC : NA
Console#
This example shows information about a detected intrusion.
Console#show port security interface ethernet 1/2
Global Port Security Parameters
Secure MAC Aging Mode : Disabled
Port Security Details
Port : 1/2
Port Security : Enabled
Port Status : Secure/Up
Intrusion Action : None
Max MAC Count : 0
Current MAC Count : 0
Table 50: show port security - display description
Field Description
Port Security The configured status (enabled or disabled).
Port Status The operational status:
â—†
Secure/Down – Port security is disabled.
â—†
Secure/Up – Port security is enabled.
â—†
Shutdown – Port is shut down due to a response to a port security violation.
Intrusion Action The configured intrusion response.
MaxMacCnt The maximum number of addresses which can be stored in the address table for
this interface (either dynamic or static).
CurrMacCnt The current number of secure entries in the address table.
