Edge-Core AS5700-54X User Manual

Chapter 10 | Interface Commands
Transceiver Threshold Configuration
– 385 –
Example
Console#show interfaces transceiver ethernet 1/25
Information of Eth 1/7
Connector Type : LC
Fiber Type : Multimode 50um (M5), Multimode 62.5um (M6)
Eth Compliance Codes : 1000BASE-SX
Baud Rate : 2100 MBd
Vendor OUI : 00-90-65
Vendor Name : FINISAR CORP.
Vendor PN : FTLF8519P2BNL
Vendor Rev : A
Vendor SN : PFS4U5F
Date Code : 09-07-02
DDM Info
Temperature : 11.54 degree C
Vcc : 3.25 V
Bias Current : 7.21 mA
RX Power : -31.55 dBm
DDM Thresholds
Low Alarm Low Warning High Warning High Alarm
----------- ------------ ------------ ------------ ------------
Temperature(Celsius) -123.00 0.00 70.00 75.00
Voltage(Volts) 3.10 3.15 3.45 3.50
Current(mA) 6.00 7.00 90.00 100.00
RxPower(dBm) -21.50! -21.00! -3.50 -3.00
Console#
The following example shows information for a 40G transceiver.
Console#show interfaces transceiver ethernet 1/54
Information of Eth 1/54
Connector Type : No Separable Connector
Fiber Type : Multimode Mode
40G Eth Compliance : 40GBASE-CR4
Baud Rate : 0 MBd
Vendor OUI : 41-50-48
Vendor Name : Amphenol
Vendor PN : 603020007
Vendor Rev : A
Vendor SN : APF12150073U30
Date Code : 12-04-21
DDM Information
Temperature : 1.50 degree C
Vcc : 0.00 V
Bias Current(ch 1) : 0.00 mA
Bias Current(ch 2) : 0.00 mA
Bias Current(ch 3) : 0.00 mA
Bias Current(ch 4) : 0.00 mA
RX Power(ch1) : -40.00 dBm
RX Power(ch2) : -40.00 dBm
RX Power(ch3) : -40.00 dBm
RX Power(ch4) : -40.00 dBm
DDM Thresholds
Low Alarm Low Warning High Warning High Alarm
----------- ------------ ------------ ------------ -----------
Temperature(Celsius) 35.03 0.00 0.00 13.00
Voltage(Volts) 0.20 2.88 1.67 0.00
Current(mA) 5.15 36.01 0.00 33.34
RxPower(dBm) -0.85 -0.85 -0.85 1.50
Console#
