Chapter 18
| VLAN Commands
Configuring L2CP Tunneling
– 495 –
(a) all access ports for which L2PT has been disabled, and (b) all uplink
ports.
â–
recognized as a Generic Bridge PDU Tunneling (GBPT) protocol packet (i.e.,
having the destination address 01-00-0C-CD-CD-D0), it is forwarded to the
following ports in the same S-VLAN:
â–
other access ports for which L2PT is enabled after decapsulating the
packet and restoring the proper protocol and MAC address
information.
â–
all uplink ports.
â—† When a Cisco-compatible L2PT packet is received on an access port, and
â–
recognized as a CDP/VTP/STP/PVST+ protocol packet, and
â–
L2PT is enabled on this port, it is forwarded to the following ports in the
same S-VLAN: (a) other access ports for which L2PT is enabled, and
(b) uplink ports after rewriting the destination address to make it a
GBPT protocol packet (i.e., setting the destination address to 01-00-0C-
CD-CD-D0).
â–
L2PT is disabled on this port, it is forwarded to the following ports in
the same S-VLAN: (a) other access ports for which L2PT is disabled, and
(b) all uplink ports.
â–
recognized as a GBPT protocol packet (i.e., having the destination address
01-00-0C-CD-CD-D0), and
â–
L2PT is enabled on this port, it is forwarded to other access ports in the
same S-VLAN for which L2PT is enabled
â–
L2PT is disabled on this port, it is forwarded to the following ports in
the same S-VLAN: (a) other access ports for which L2PT is disabled, and
(b) all uplink ports.
â—† For L2PT to function properly, QinQ must be enabled on the switch using the
dot1q-tunnel system-tunnel-control command, and the interface configured to
802.1Q uplink mode using the switchport dot1q-tunnel mode command.
Example
Console(config)#dot1q-tunnel system-tunnel-control
Console(config)#l2protocol-tunnel tunnel-dmac 01-80-C2-00-00-01
Console(config-)#
