Chapter 23
| LLDP Commands
– 676 –
Example
Note that an IP phone or other end-node device which advertises LLDP-MED
capabilities must be connected to the switch for information to be displayed in the
“Device Class” field.
Console#show lldp info remote-device
LLDP Remote Devices Information
Interface Chassis ID Port ID System Name
--------- ----------------- ----------------- ---------------------
Eth 1/1 00-E0-0C-00-00-FD 00-E0-0C-00-01-02
Console#show lldp info remote-device detail ethernet 1/1
LLDP Remote Devices Information Detail
----------------------------------------------------------------------------
Index : 1
Chassis Type : MAC Address
Chassis ID : 70-72-CF-80-0E-50
Port ID Type : MAC Address
Port ID : 70-72-CF-80-0E-51
Time To Live : 120 seconds
Port Description : Ethernet Port on unit 1, port 1
System Description : ECS4120-28P
System Capabilities : Bridge, Router
Enabled Capabilities : Bridge, Router
Management Address : 70-72-CF-80-0E-50 (MAC Address)
Port VLAN ID : 1
Port and Protocol VLAN ID : supported, disabled
VLAN Name : VLAN 1 - DefaultVlan
Protocol Identity (Hex) : 05-DC-42-42-03-00-00-00
05-DC-42-42-03-00-00-02
05-DC-42-42-03-00-00-03
88-09-01-01
88-8E-01
88-CC
89-02
MAC/PHY Configuration/Status
Port Auto-neg Supported : Yes
Port Auto-neg Enabled : Yes
Port Auto-neg Advertised Cap (Hex) : 0000
Port MAU Type : 0
Power via MDI
Power Class : PSE
Power MDI Supported : Yes
Power MDI Enabled : Yes
Power Pair Controllable : Yes
Power Pairs : Signal
Power Classification : Class 1
Link Aggregation
Link Aggregation Capable : Yes
Link Aggregation Enable : No
Link Aggregation Port ID : 0
Max Frame Size : 1522
