C
HAPTER
3
| Using the Web Interface
Navigating the Web Browser Interface
– 89 –
MAC-Based 191
Add Maps traffic with specified source MAC address to a VLAN 191
Show Shows source MAC address to VLAN mapping 191
Mirror 193
Add Mirrors traffic from one or more source VLANs to a target port 193
Show Shows mirror list 193
MAC Address 195
Static 195
Add Configures static entries in the address table 195
Show Displays static entries in the address table 195
Dynamic
Configure Aging Sets timeout for dynamically learned entries 197
Show Dynamic MAC Displays dynamic entries in the address table 198
Clear Dynamic MAC Removes any learned entries from the forwarding database and
clears the transmit and receive counts for any static or system
configured entries
199
Mirror Mirrors traffic matching a specified source address from any port on
the switch to a target port
200
Spanning Tree 203
Loopback Detection Configures Loopback Detection parameters 206
STA Spanning Tree Algorithm
Configure Global
Configure Configures global bridge settings for STP, RSTP and MSTP 207
Show Information Displays STA values used for the bridge 212
Configure Interface
Configure Configures interface settings for STA 213
Show Inform at on Displays interface settings for STA 217
MSTP Multiple Spanning Tree Algorithm 220
Configure Global 220
Add Configures initial VLAN and priority for an MST instance 220
Modify Configures the priority or an MST instance 220
Show Configures global settings for an MST instance 220
Add Member Adds VLAN members for an MST instance 220
Show Member Adds or deletes VLAN members for an MST instance 220
Show Information Displays MSTP values used for the bridge
Configure Interface 224
Configure Configures interface settings for an MST instance 224
Show Information Displays interface settings for an MST instance 224
Table 6: Switch Main Menu (Continued)
Menu Description Page
