6.5 Replacing Parts

357

6. Replace the pick roller.

1. Open the sheet guide.

Slide the side guides all the way, and pull the sheet guide open from the dip.

2. Rotate the lock release tab on the shaft in the direction of the arrow.

Sheet guide

Dip

Side guides

Lock release tab
