6.5 Replacing Parts

358

3. Remove the pick roller.

Slightly lift the Lock release tab of the shaft (by approximately 5 mm), slide the

shaft to the direction of the arrow below, and lift it up all the way.

ATTENTION

Be careful not to touch the gear near the lock release tab on the shaft as it contains

grease.

Lock release tab
