5.3.18 Performing a fan test
Notes on replacing a defective fan
After replacing a defective system fan or PSU containing a defective fan,
the fan error indicators will stay lit until the next fan test. By default, a fan
test is automatically started every 24 hours. The first automatic fan test
being performed after replacing a fan will turn of
f the fan error indicator.
If you want to start the fan test manually, you can do so by following the
description below:
Executing the fan test via the iRMC S6 web interface
▶
Log into the iRMC S6 web interface.
The System menu is displayed on default.
▶
Open the Cooling page.
▶
Expand the Cooling Devices
group.
▶
Click Start Fan Test.
For more information on iRMC settings, see the iRMC user guides.
In case of maintenance done by Fujitsu engineers in Japan:
Executing the fan test via Chassis ID Prom T
ool
Please follow the instructions provided separately.
5.3.19 Updating the golden image
5.3.19.1
Updating the golden image for iRMC S6 firmware
The golden image is part of the PFR (Platform Firmware Resiliency)
feature.
The PFR feature provides protection of firmware, detection of tampered
firmware and automatic recovery of firmware.
Basic software procedures
RX2540 M7 Upgrade and Maintenance Manual 117

Fujitsu PRIMERGY RX2540 M7 Specifications

General

Form Factor	2U rack server
Processor	Intel Xeon Scalable Processors
Storage	Up to 24 x 2.5-inch drives or 12 x 3.5-inch drives
RAID	Integrated RAID controller with support for RAID 0/1/5/6/10/50/60
Network	optional 10/25GbE
Power Supply	Redundant power supplies; 800W, 1300W, or 1600W
Expansion Slots	Up to 8 x PCIe slots
Operating System Support	Windows Server, Red Hat, SUSE, VMware
