Installing the new serial interface
▶
Install the serial interface, see "Installing the serial interface" on page
479.
Concluding steps
▶
"Reassembling" on page 59.
▶
"Connecting the power cord" on page 65.
▶
"Switching on the server" on page 71.
▶
If applicable, "Installing the front cover with lock" on page 71.
16.3 Rear VGA connector
16.3.1 Replacing the rear VGA connector
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools:
– Phillips PH2 / (+) No. 2 screw driver (for cover 2)
–
Hexagon screw driver 5 mm
Preliminary steps
▶
If applicable, "Removing the front cover with lock" on page
49.
▶
"Shutting down the server" on page 50.
▶
"Disconnecting the power cord" on page 50.
▶
"Getting access to the component" on page 55.
▶
Remove the riser module 2, see "Removing a riser module" on page 72.
Additional interfaces
RX2540 M7 Upgrade and Maintenance Manual 485
