Fujitsu PRIMERGY RX2540 M7

Installing the top cover 1
Figure 13: Installing the top cover 1
▶
Insert the top cover 1 in a slight angle (1).
CAUTION
▶
Take care that all cables are inside the chassis.
▶
Fold the top cover 1 down (2).
4.6.3
Installing the server in the rack
For information on mounting the server in the rack, see the "Mounting
Instructions" provided with the Rack Mounting Kit. For more information,
see the manual of your rack system.
For Japan, see also the "Rack system structure guide" and the "Rack
Rail Kit Installation Instructions".
Online documentation for rack installation can be found at https://
support.ts.fujitsu.com under Product - Rack & Components.
For Japan:
https://jp.fujitsu.com/platform/server/primergy/manual/peri_rack.html
CAUTION
At least two people are needed to position the server on the rack rails.
(For Japan, see "安全上のご注意".)
Basic hardware procedures
RX2540 M7 Upgrade and Maintenance Manual 61
