"Locating the defective component" on page
48.
Removing the defective expansion card
▶
Remove the internal RAID riser module, see "Removing the internal RAID
riser module" on page 305.
▶
Remove the RAID controller, see "Removing the RAID controller" on
page 304.
Installing the new expansion card
▶
Install the RAID controller, see "Installing the RAID controller" on page 300.
▶
Install the internal RAID riser module, see "Installing the internal RAID riser
module" on page 299.
Concluding steps
▶
"Installing the fan cage" on page 77.
▶
"Reassembling" on page 59.
▶
If applicable, connect external cables to the expansion card.
▶
"Connecting the power cord" on page 65.
▶
"Switching on the server" on page 71.
▶
If applicable, "Installing the front cover with lock" on page 71.
▶
"Enabling replaced components in the BIOS" on page 102.
▶
"Updating expansion card firmware" on page 98.
▶
"Resuming BitLocker functionality" on page 107.
9.8.4 Replacing a riser card
Field Replaceable Unit
(FRU)
Hardware: 5 minutes
Expansion cards and backup units
RX2540 M7 Upgrade and Maintenance Manual 307
