Configuration with up to 24 2.5-inch PCIe SSDs and up to 6 2.5-inch
rear HDDs/SSDs without SAS expander board - part 2
Position Enclosure Slot
16ch HBA/
RAID (0)
Rear HDD
without
Expander
[0] 1 0
[1] 1 1
[2] 1 2
[3] 1 3
[4] 1 4
[5] 1 5
Table 15: iRMC S6 web interface display
Information about HDD/SSD slots can also be displayed using the BIOS,
see "Displaying HDD/SSD slot information" on page
143.
7.6.2 Installing 2.5-inch HDD/SSD modules
Customer Replaceable
Unit (CRU)
Hardware: 5 minutes
Tools: tool-less
Preliminary steps
▶
If applicable, "Removing the front cover with lock" on page
49.
▶
Locate the correct drive bay, see "Overview of configurations" on page 165.
Removing a 2.5-inch HDD/SSD dummy module
Unusable HDD bays contain a HDD/SSD dummy with dummy lock to
prevent customer from erroneously adding a HDD.
Hard disk drive (HDD) / solid state disk (SSD)
RX2540 M7 Upgrade and Maintenance Manual 177
