If applicable, update the system information of your server using the Chassis
ID Prom T
ool, see "Using the Chassis ID Prom Tool" on page 113.
▶
"Updating expansion card firmware" on page 98.
▶
"Resuming BitLocker functionality" on page 107.
9.7.2 Removing a GPU card from a riser module
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Software: 5 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
Preliminary steps
▶
"Suspending BitLocker functionality" on page
89.
▶
If applicable, "Removing the front cover with lock" on page 49.
▶
"Shutting down the server" on page 50.
▶
"Disconnecting the power cord" on page 50.
▶
"Getting access to the component" on page 55.
▶
Remove all riser modules, see "Removing a riser module" on page 72.
▶
"Removing an expansion card from a riser module" on page 313.
▶
If necessary, remove the cables from the expansion cards.
▶
"Removing the air duct" on page 80.
▶
Disconnect the GPU power cable from the system board connector.
Removing the GPU card from a riser module (example GPU NVIDIA A16)
The GPU cards A30/A40/A100/H100/RTX A4500/RTX A6000/A30X/
A100X have the same removal procedure.
Expansion cards and backup units
290 Upgrade and Maintenance Manual RX2540 M7
