Loosen the two screws.
▶
Remove the expansion card with the serial interface.
Concluding steps
▶
Install the riser module 1, see "Installing a riser module" on page
74.
▶
If applicable, install a slot bracket in PCIe slot 5, see "Installing the front
cover with lock" on page 71.
▶
"Reassembling" on page 59.
▶
"Connecting the power cord" on page 65.
▶
"Switching on the server" on page 71.
▶
If applicable, "Installing the front cover with lock" on page 71.
16.2.3 Replacing the serial interface
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: – Phillips PH2 / (+) No. 2 screwdriver (for cover 2)
–
hexagon screwdriver 5 mm
Preliminary steps
▶
If applicable, "Removing the front cover with lock" on page
49.
▶
"Shutting down the server" on page 50.
▶
"Disconnecting the power cord" on page 50.
▶
"Getting access to the component" on page 55.
Removing the defective serial interface
▶
Remove the serial interface, see "Removing the serial interface" on
page 482.
Additional interfaces
484 Upgrade and Maintenance Manual RX2540 M7
