14 Thermal sensor
14.1
Replacing the thermal sensor
Field Replaceable Unit
(FRU)
Hardware: 10 minutes
Tools: – Phillips PH2 / (+) No. 2 screw driver (for cover 2)
–
Phillips PH1 / (+) No. 1 screw driver (for the thermal sensor)
Preliminary steps
▶
"Locating the defective server" on page
47.
▶
If applicable, "Removing the front cover with lock" on page 49.
▶
"Shutting down the server" on page 50.
▶
"Disconnecting the power cord" on page 50.
▶
"Getting access to the component" on page 55.
▶
If applicable, "Removing the riser module 2" on page 73.
▶
"Removing the fan cage" on page 76.
▶
"Removing the air duct" on page 80.
▶
Remove all HDD modules, see "Removing 2.5-inch HDD/SSD modules" on
page 180 or "Removing 3.5-inch HDD modules" on page 153.
The proceeding for installing/removing is identic for the 2.5-inch or 3.5-
inch HDD configuration.
RX2540 M7 Upgrade and Maintenance Manual 455
